Product Description
Feature :
- Constant voltage design
- Universal AC input/ Full range
- Withstand 300VAC surge input for 5 seconds.
- Protections: Short circuit/Overload/Over voltage
- Cooling by free air convection
- Fully encapsulated with IP67 level
- Fully isolated plastic case
- Suitable for LED related fixture or appliance (such as LED Decoration or Advertisement devices)
- 100% full load burn-in test
- Low cost, high reliability
- 2 years warranty.
Technical Data :
| Output voltage: | 12V |
| Output power: | 36W |
| MAX output current: | 3A |
| Water resistance: | IP67 |
| Operating temperature: | -30~ +65C |
| Overload protection: | Yes (Hiccup) |
| Surge protection: | Yes (Hold & Restart) |
| Security certificates: | UL1310 class 2, CAN/CSA No. 223-M91, IP67 approved , design refer to TUV EN60950-1 |
| Dimensions: | 148 x 40 x 30mm |
| Weight: | 340g |
Download Factsheet
